Motors for boats Marine Power USA (USA) from the American company of the same name, located in California, are known for their reliability and simplicity in operation.

    The lineup of gasoline stationary marine engines includes about 40 modifications based on GM (General Motors) units - from 3 to 7.4 liters

    Also, this company is known for its jet engines designed for installation on boats and boats of various classes, interchangeable with gasoline engines Mercruiser and Volvo Penta, cylinder blocks (short blocks), complete motors.

The Marine Power 6.2 engine is a light version of the 6.2LSA "big brother" solution for replacing your old MerCruiser, OMC or Volvo Penta engine. The motor is ready for installation in a boat with any type of speakers and transom assemblies.

Compatible with modern MEFI 6 fuel injection to improve performance and control fuel consumption.

New Marine Power engines are built for industry-leading performance in sports. Improved fuel supply system, which prevents fuel starvation of the engine during tight turns, when operating boats in various competitions, towing skiers and wakeboarders.

Marine Power 6.2 Engine Specifications

Displacement 6162cc

Compression Ratio 11.5: 1

Valve Configuration Overhead Valves (2 valves per cylinder)

Valve Lifters Hydraulic Roller

Firing Order 1 - 8 - 7 - 2 - 6 - 5 - 4 - 3

Bore x Stroke 103.25 x 92 mm

Fuel System DI

Fuel Type Premium Fuel recommended, not required

Engine Orientation Longitudinal

Bore Center (mm) 111.76

Emission Controls Catalytic Converter, Three-Way Catalyst, Positive Crankcase Ventilation

Horsepower 420 hp (313 kW) @ 5600 rpm

Torque 460 lb-ft (624 Nm) @ 4100 rpm
