Nissamaran Electric Outboard motors owner's manual

Nissamaran

Nissamaran boat motors are low power electric motors. Quiet, environmentally friendly, with a low smooth ride, they are perfect for anglers. NISSANMARAN outboard motors are often used as the main motor on light boats or as a spare on medium-sized boats.

These outboard motors have become popular due to their versatility, low weight (which makes it easy to carry and install), decent traction in all operating modes, and, importantly, the absence of noise, which, when fishing with a conventional outboard motor, reduces the fishing efficiency.

The Nissamaran Ecomotor 55 Pro electric motor has a weight of only 7.5 kg, while it can move a boat with a maximum weight of up to 1150 kg. with a pulling force of 24.8 kg.! And all this, besides, at an affordable price.

The lightweight and durable motor housing has been developed for a long time and has become available thanks to the use of high-tech composite materials. The motor runs on battery power, and its charge is always displayed using 10 LEDs, so you can always calculate the remaining work time.

THE NISSAMARAN ELECTRIC MOTOR IS YOUR CHOICE IF YOU PREFER A COMFORTABLE, ECONOMICAL, CONVENIENT AND ENVIRONMENTALLY CLEAN REST!

Specifications Nissamaran Ecomotor 55 Pro

Model 55 Pro

Capacity (lb • S) 55

Power, h.p. 0.82

Tractive effort, kg 24.8

Weight, kg 7.5

Max. boat weight, kg 1150

Max. current, A 54

Leg length, cm. 92

Battery discharge indicator LED, 10 levels

Tiller, mm Telescopic + 16cm

Trim angle 10 positions

Speed 5 forward / 3 reverse
